D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
48
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the parameters that control the operation of the authenticator associated with a port:
DGS-3120-24TC:admin# config 802.1x auth_parameter ports 1:1-1:20 direction
both
Command: config 802.1x auth_parameter ports 1:1-1:20 direction both
Success.
DGS-3120-24TC:admin#
4-14 config 802.1x auth_mode
Description
This command is used to configure 802.1X authentication mode.
Format
config 802.1x auth_mode [port_based | mac_based]
Parameters
port_based - Configure the authentication as port based mode.
mac_based - Configure the authentication as MAC based mode.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the authentication mode:
DGS-3120-24TC:admin# config 802.1x auth_mode port_based
Command: config 802.1x auth_mode port_based
Success.
DGS-3120-24TC:admin#
4-15 config 802.1x init
Description
This command is used to initialize the authentication state machine of some or all ports.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
