xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
545
01-00-0C-CC-CC-CD - Specify the MAC address as 01-00-0C-CC-CC-CD.
all - All tunnel-abled Layer 2 protocols will be tunneled on the ports.
threshold - (Optional) Specify the drop threshold for packets-per-second accepted on the
UNI ports. The ports drop the PDU if the protocol’s threshold is exceeded.
<value 0-65535> - The range of the threshold value is 0 to 65535 (packet/second). The
value 0 means no limit. By default, the value is 0.
nni - Specify the ports as NNI ports.
none - Disable tunnel on it.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the STP tunneling on ports 1-4:
DGS-3120-24TC:admin#config l2protocol_tunnel ports 1:1-1:4 type uni
tunneled_protocol stp
Command: config l2protocol_tunnel ports 1:1-1:4 type uni tunneled_protocol stp
Success.
DGS-3120-24TC:admin#
51-4 show l2protocol_tunnel
Description
This command is used to display Layer 2 protocol tunneling information.
Format
show l2protocol_tunnel {[uni | nni]}
Parameters
uni - (Optional) Specify to show UNI detail information, include tunneled and dropped PDU
statistic.
nni - (Optional) Specify to show NNI detail information, include de-capsulated Layer 2 PDU
statistic.
Restrictions
None.
Example
To show Layer 2 protocol tunneling information summary:
