D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
550
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure link aggregation algorithm for mac-source-dest:
DGS-3120-24TC:admin# config link_aggregation algorithm mac_source_dest
Command: config link_aggregation algorithm mac_source_dest
Success.
DGS-3120-24TC:admin#
52-5 show link_aggregation
Description
This command is used to display the current link aggregation configuration on the Switch.
Format
show link_aggregation {group_id <value 1-32> | algorithm}
Parameters
group_id - (Optional) Specify the group id. The group number identifies each of the groups.
<value 1-32> - Enter the group ID value here. This value must be between 1 and 32.
algorithm - (Optional) Allows you to specify the display of link aggregation by the algorithm in
use by that group.
If no parameter specified, system will display all link aggregation information.
Restrictions
None.
Example
Link aggregation group enable:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
