DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
621
Format
config mirror group_id <value 1-4> {target_port <port> | [add | delete] source ports
<portlist> [rx | tx | both] | state [enable | disable]}(1)
Parameters
<value 1-4> - Enter a mirro group identify value.
target_port - The port that receives the packets duplicated at the mirror port.
<port> - Specify the port.
add - Add the mirror source ports.
delete - Delete mirror source ports.
source ports – Specify the mirror group source ports.
<portlist> - Enter a list of ports.
rx - Only the received packets on the mirror group source ports will be mirrored to the
mirror group target port.
tx - Only the sent packets on the mirror group source ports will be mirrored to the mirror
group target port.
both - Both the received and sent packets on the mirror group source ports will be
mirrored to the mirror group target port.
state - Specify the mirror group state.
enable - Enable the mirror group function.
disable - Disable the mirror group function.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To configure mirror group 3 with state enable and add source ports 1:4-1:9:
DGS-3120-24TC:admin#config mirror group_id 3 state enable add source ports 1:4-
1:9 both
Command: config mirror group_id 3 state enable add source ports 1:4-1:9 both
Success.
DGS-3120-24TC:admin#
60-7 delete mirror group_id
Description
This command is used to delete a mirror group.
Format
delete mirror group_id <value 1-4>
Parameters
<value 1-4> - Enter a mirro group identify value.
