D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
685
Format
config nlb unicast_fdb <macaddr> [add | delete] <portlist>
Parameters
<macaddr> - Specify the MAC address of the NLB unicast FDB entry to be configured.
add - Specify to add the ports.
delete - Specify to delete the ports.
<portlist> - Specify a list of forwarding ports to be added or removed.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure NLB unicast FDB entry, for the product that support the VLAN information on the
unicast forwarding:
DGS-3120-24TC:admin#config nlb unicast_fdb 02-BF-01-01-01-01 add 1:1-1:5
Command: config nlb unicast_fdb 02-BF-01-01-01-01 add 1:1-1:5
Success.
DGS-3120-24TC:admin#
67-3 delete nlb unicast_fdb
Description
This command is used to delete the NLB unicast FDB entry.
Format
delete nlb unicast_fdb <macaddr>
Parameters
<macaddr> - Specify the MAC address of the NLB unicast FDB entry to be deleted.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To delete the NLB unicast FDB entry, for the product that support the VLAN information on the
unicast forwarding:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
