D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
701
• Variable: It indicates that the OAM entity can send and receive variable requests to monitor the
attribute value as described in the IEEE 802.3 Clause 30 MIB.
The event log displays Ethernet OAM event log information. The switch can buffer 1000 event logs.
The event log is different from sys-log as it provides more detailed information than sys-log. Each
OAM event will be recorded in both OAM event log and syslog.
Format
show ethernet_oam ports {<portlist>} [status | configuration | statistics | event_log {index
<value_list>}]
Parameters
<portlist> - (Optional) Specify the range of ports to display.
status - Specify to display the Ethernet OAM status.
configuration - Specify to display the Ethernet OAM configuration.
statistics - Specify to display Ethernet OAM statistics.
event_log - Specify to display the Ethernet OAM event log information.
index - (Optional) Specify an index range to display.
<value_list> - (Optional) Specify an index range to display.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To display Ethernet OAM statistics information for port 1:

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
