xStack

DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide

753

Parameters

None.

Restrictions

Only Administrator, Operator and Power-User level users can issue this command.

Example

To return all the port LEDs to the normal state:

DGS-3120-24TC:admin#disable light

Command: disable light

Success.

DGS-3120-24TC:admin#
