D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
955
99-2 upload tech_support_toTFTP
Description
This command is used to upload the information of technical support to the TFTP server. The
upload information includes the following:
• Basic System information
• System log
• Running configuration
• Layer 1 information
• Layer 2 information
• Layer 3 information
• Application
• OS status
• Controller’s status
This command can be interrupted by Ctrl+C or ESC when it is executing.
Format
upload tech_support_toTFTP <ipaddr> <path_filename 64>
Parameters
<ipaddr> - Specify the IP address of TFTP server.
<path_filename 64> - Specify the file name to store the information of technique’s support in
TFTP server. The max size of the file name is 64.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To upload the information of technique’s support:
DGS-3120-24TC:admin#upload tech_support_toTFTP 10.0.0.66 tech_report.txt
Command: upload tech_support_toTFTP 10.0.0.66 tech_report.txt
Connecting to server................... Done.
Upload techsupport file................ Done.
Success.
DGS-3120-24TC:admin#

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
