ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-185
PRELIMINARY
2.) Disconnect the two power cables (seen in Figure 8-233) from the AC Box by squeezing the plastic
retainer clips inwards (Figure 8-234).
3.) Disconnect both ground leads.
4.) To remove the AC box, unscrew the two supporting screws (shown in Figure 8-233) and slide the
AC box all the way out until is completely removed from the system.
Figure 8-233 AC Box Secured with Two Supporting Screws
Figure 8-234 Plastic Securing Clips on Power Cables
Disconnect
Two
Power Cables
AC Box
Supporting Screws
Ground Leads
To Next Page
