4.4 Judging Measurement Results

99

4

Chapter 4 LCR Function

6

Use or to select the BIN number to

set, and press .

BIN Settings

Press .

Use the numeric keypad to enter the reference

value and press .

Settable range: -9.999999G to 9.99999G

4

Press to return to the BIN setting

screen.

5

Reference Value Setting

BIN Mode Setting
