6.1 Initial Screen
265
6
Chapter 6 Continuous Measurement Function
The continuous measurement function reads in order the measurement conditions saved with the panel save
function, and performs a number of measurements continuously. It is possible to mix the measurement condi-
tions of the LCR and analyzer.
The continuous measurement of up to 32 items is possible.
For details on the screen configuration (p. 20).
Continuous Measurement
Function Chapter 6
6.1 Initial Screen
• Setting the measurement conditions so that the measurement frequency or measure-
ment signal level differs for each panel allows you to simply evaluate the characteristics
of the test sample.
• Continuous measurement can also be performed from the EXT I/O.(p. 364)
• If the power is turned off when the [Continuous Measurement Screen] is displayed, the [Contin-
uous Measurement Screen] will be displayed when the instrument starts the next time you turn
the power on.
Menu keys
Select the measurement mode.
(p. 13)
Set the continuous measurement
settings.(p. 266)
Set the save settings. (p. 329)
Scrolls the list.
Indicates the usage status
of internal memory.
(p. 106), (p. 219)
Indicates that a USB
flash drive is connected.
(p. 329)
Displays a list of panels for
which continuous measurement
is to be performed.
Indicates the
interface that is
currently set.
An operation key is displayed depending on the situation.
Operation keys
Saves the measurement results. (p. 333)
Prints the measurement data. (p. 381)Displays a sweep measurement graph. (p. 268)
Starts continuous measurement. (p. 267)
To Next Page
