9.3 Changing a Panel Name

324

You can change the name of a panel saved to the instrument.

9.3 Changing a Panel Name

Procedure

Use or to select the number of the

panel to rename.

3

1

Press .

2

Press .

LCR Initial Screen Application Settings

Application Settings

Panel Main Screen

When you want to cancel saving:

Press .
