Hioki IM3570 - Auto Search Setting

5.6 Checking the Measurement Values
192
The filter setting is common to cursors A and B.
6
Auto Search Setting
Filter Setting
This can be set when or is selected for the search function setting.
See "Performing Measurement Value Search" (p. 194)
Set the filter.
• When judging the local maximum value or local minimum value, set a filter.
• Applying a filter allows you to reduce the misjudgments of variations in measurement values
caused by noise and other interference being judged as local maximum values or local mini-
mum values.
Set the filter type.
Disables the filter function.
Enables the filter function.
Auto Search Setting
If you turn auto search ON, the search function is
executed after sweep measurement ends, and the
cursors move in accordance with the search set-
tings.
Disables the auto search function.
Enables the auto search function.
