4.2 Setting Basic Settings of Measurement Conditions
55
4
Chapter 4 LCR Function
Triggering is the process of controlling the start and stop of recording by specific signals or conditions (crite-
ria). When recording is started or stopped by a specific signal, we say the trigger is "gapplied" or "triggering
occurs".
With this instrument, you can select the following two types of trigger.
4.2.4 Perform Measurements with User-defined
Timing (Trigger Measurement)
Internal Trigger
Trigger signals are automatically generated internally for continuous
measurement.
External trigger
Measurements are triggered by an external signal.
Manual measurement triggering is also available.
Procedure
LCR Initial Screen LCR Basic Settings
1
Press .
2
LCR Basic Settings
