12.2 Instrument and Printer Settings
383
12
Chapter 12 Printing
12.2 Instrument and Printer Settings
Make Instrument Settings
1
LCR Initial Screen Interface Setting
Procedure
This operation is possible in any of the mode, mode.
2
Printer Setting
Press and select the printing method.
In analyzer mode, [TYPE] cannot be selected.
Only the screen can printed.
Prints the measurement results as
text.
Prints the screen.
BAUD RATE Communication speed with the
printer
HANDSHAKE Configuring flow control
Manual Print
Outputs the measurement values only
when of the initial screen is
pressed.
Auto Print
Outputs the measurement values after
measurement finishes.
3
Select and check each of the settings, and press to close the setting screen.
The printer's communication speed (baud rate) and flow control settings are the same as the RS-232C settings. If the
communication speed is changed, you may need to increase the print speed. It is also necessary to change the print-
er's communication speed setting. When the communication speed is increased, the printer may be unable to keep
up, preventing data from being printed properly. If this occurs, use hardware or software flow control. For more infor-
mation, see the instruction manual that came with the printer.
