1.3 Screen Configuration and Operation
14
This screen is for configuring the measurement conditions you want to change and other advanced settings.
Select the measurement mode (p. 13) before configuring the advanced settings.
1.3.3 Advanced Settings Screen
1
Press .
2
LCR Initial Screen
LC on figure the settings of each of the LCR mode, analyzer mode, and continuous measure-
ment mode.
Procedure
LCR Mode
Basic setting
Measurement frequency setting (p. 41)
Measurement signal level setting (p. 43)
Measurement range setting (p. 49)
Measurement speed setting (p. 59)
Voltage and current limit settings (p. 60)
Average setting (p. 62)
Trigger delay setting (p. 64)
Trigger setting (p. 55)
DC bias setting (p. 57)
Initial screen is displayed.
