Hioki IM3570 - Setting the Upper or Lower Limit Value as an; (Absolute Value Mode)

4.4 Judging Measurement Results
88
1
Setting the Upper or Lower Limit Value as an Absolute Value (ABS)
(Absolute Value mode)
Procedure
1
Press .
5
Press and use the numeric keypad to
set the upper limit value.
4
Press to confirm the upper limit value.
Return to step 2, press , use the numeric keypad to set the lower limit value,
and press .
Press .
2
3
LCR Initial Screen
Comparator Condition Setting
Upper Limit Value Setting
6
Press to close the setting screen.
Settable range: -9.999999 G to 9.999999 G
Settable range: -9.999999 G to 9.999999 G
When you do not want to set the upper and
lower limit values: Press .
Changing the unit (a/ f/ p/ n/ / m/ None/ k/ M/ G)
Step the units up.
Step the units down.
