4.4 Judging Measurement Results

102

6

Use or to select the BIN number

to set, and press .

BIN Settings

Press .

Use the numeric keypad to enter the reference

value and press .

Settable range: -9.999999G to 9.999999G

Press to return to the BIN setting

screen.

5

BIN Mode Setting

4

Reference Value Setting
