5.5 Setting the Graph Display Method
186
Set the sweep parameter for which to display grid lines.
5.5.3 Setting Grid Display
Procedure
Analyzer Initial Screen
4
Press to close the setting screen.
3
Press .
2
Graph Settings
Graph Settings
Grid Display Setting
Select the sweep parameter for which to display
grid lines.
Displays grid lines for sweep parameter 1.
Displays grid lines for sweep parameter 2.
1
