5.3 Normal Sweep

143

Chapter 5 ANALYZER Function

Set just one type for each of the sweep range and number of sweep points and then perform measurement.

The sweep range setting differs depending on the setting of the sweep parameter ( ). (p. 135)

• When (p. 143)

• When or (p. 148)

• When (p. 152)

5.3 Normal Sweep

5.3.1 Setting Sweep Points

When the setting is

LCR

ANALYZER

Do not switch between V, CV and CC while the test sample is still connected to the measurement termi-

nals because doing so may damage the test sample. (p. 45)

Procedure

Analyzer Initial Screen

Press .

Analyzer Basic Settings
