13.1 General Specifications
1.Basic Specifications
Measurement mode (1) LCR mode: Measurement with single condition
(2) Analyzer mode: Measurement frequency sweep, measurement level sweep
• Measurement points: 2 to 801
• Sweep method: Normal sweep/segment sweep
Normal sweep: START-STOP/ CENTER-SPAN/ START-STEP, maximum 801 points
Segment sweep: START-STOP, maximum 20 segments (total of 801 points)
• Display: List display/graph display
(3) Continuous measurement mode: Consecutive measurements with saved conditions
• LCR mode: Up to 30 conditions
• Analyzer mode: Up to 2 conditions
* Continuous measurements including a mixture of LCR mode and analyzer mode are
possible.
Measurement items Z (Impedance), Y (Admittance), (Phase angle), Rs (Equivalent series resistance (ESR)),
Rp (Parallel equivalent resistance), X (Reactance), G (Conductance), B (Susceptance),
Ls (Series equivalent inductance), Lp (Parallel equivalent inductance), Cs (Series equivalent
capacitance), Cp (Parallel equivalent capacitance), Q (Q factor), D (Loss coefficient tan
,
Rdc (DC resistance)
Display range Z, Y, Rs, Rp, Rdc, X, G, B, Ls, Lp, Cs, Cp: ± (0.000000 (unit) to 9.999999G (unit))
* Absolute value display for Z and Y only
: ± (0.000° to 999.999°)
D: ± (0.000000 to 9.999999)
Q:
± (0.00 to 99999.99)
%: ± (0.0000% to 999.9999%)
* DISP OUT is displayed when the upper limit is exceeded.
Measurement frequency (1)Frequency range
4 Hz to 5 MHz
(2)Setting resolution
5-digit resolution (however, the minimum resolution is 10 mHz)
(3)Frequency accuracy
±0.01%
Output impedance
(Hc terminal, when 1 kHz)
Normal mode: 100 ±10 
Low impedance accuracy mode: Approx. 10 (100 m and 1  ranges of 100 kHz or less)
Approx. 100
 (Except for the above)
* The following impedances are connected to the Lc terminal.
1  range or less (100 kHz or less) when low impedance high accuracy mode: 5  or less
1 V or less of other than the above:
3 k range or more...............Approx. 35 
1 k range or less...............Approx. 5 
1.001 V or more of other than the above:
30 k range or more...............Approx. 35 
10 k range or less...............Approx. 5 
