12.3 Printing

386

The measured value display will be printed in text, or the graph display will be printed as a screen image.

When Continuous Measurement Mode

Measured value display

Graph display

Since printer settings cannot be configured in continuous measurement mode, set the instru-

ment to either LCR mode or analyzer mode in order to changing the printer settings.
