4.4 Judging Measurement Results

95

4

Chapter 4 LCR Function

1

Setting the Upper or Lower Limit Value as an Absolute Value (ABS)

(Absolute Value mode)

Procedure

1

Press .

2

Press .

3

Press .

Press to return to the BIN setting

screen.

BIN Settings

BIN Mode Setting

The button display differs depending on the

measurement parameter.
