10.6 Saving Instrument Settings
351
8
10
Chapter 10 Using USB Flash Drive
Save various setting information of the instrument including the panel save information as a setting file to the
USB flash drive.
The extension of the setting file is “.SET.” The extension of the panel save is “.PNL.”
For the settings that are saved, refer to "Appendix 12 Initial Settings Table" (p. A17).
2
Saving All Settings of Instrument (ALL SAVE Function)
Procedure
2
Press .
3
LCR Initial Screen File List Screen
File List Screen
Insert the USB flash drive into the USB port (front panel).
1
