10.6 Saving Instrument Settings

350

4

Press in the save confirmation

screen.

The measurement data is saved.

Save Instrument Settings

When you want to cancel saving:

Press .

• The setting file is saved to the [SETTING] folder

in the USB flash drive.

• The date and time are automatically assigned to

the file name.
