5.6 Checking the Measurement Values
194
You can perform a measurement value search for the measurement results of one sweep using the method
set in the search function setting ( , , , , or ).
When you perform a search, the cursor moves to the search result point so that you can check the search
execution result. (p. 193)
The search target parameter is the parameter set in "Search Target Parameter Setting" (p. 191)
( or ).
5.6.3 Performing Measurement Value Search
Procedure
1
Measurement Value List Display
Analyzer Initial Screen
Press to change to [Graph Display]
before you set the cursor.
2
Analyzer Initial Screen
Press to move the cursor to the
sweep point that matches the condition set for
the search function setting.
If more than one search point matches the con-
dition, the cursor moves each time you press
.
A search cannot be performed when the trigger setting is .
See "5.2.3 Setting the Trigger" (p. 137)
To Next Page
