Hioki IM3570 - Performing Equivalent Circuit Analysis

5.10 Equivalent Circuit Analysis Function
253
5
Chapter 5 ANALYZER Function
When the method of analysis is set to AUTO, analysis is performed automatically after measurement com-
pletes, and the results are displayed.
When the method of analysis is set to MANUAL, analysis is performed when is pressed.
2
Performing equivalent circuit analysis
Equivalent circuit analysis results (normal measurement)
Equivalent circuit analysis results (X-Y display)
Analysis result
(normal measurement)
Analysis result
(X-Y display)
1
2
Measurement Screen
Press .
Measurement Screen
Press to perform analysis.
Procedure
