Hioki IM3570 - 7.3 Compensating Values to Match

7.3 Compensating Values to Match Reference Values (Load Compensation)
292
If you select , the compensation
values are acquired.
• When data acquisition is completed, the reference
sample compensation data is displayed on the
screen.
• When an error occurs during data acquisition, a
“beep” sound is generated and the compensation
data is invalidated.
• If even one of the load compensation conditions is
changed following data acquisition, the acquired
compensation data is invalidated.
When you want to cancel compensation data
acquisition: Press .
When compensation failed: (p. 300)
7
Load Compensation Value List
Performing Load Compensation
8
Load Compensation Value List
Press from the load compensation
screen to return to the initial screen.
When acquisition of the compensation value is
completed, the compensation value is displayed.
