12.3 Printing

384

Before Printing

Verify that the instrument and printer settings (p. 383) are correct.

Prints automatically after measurement completes.

Prints the state when is pressed in the initial screen.

12.3 Printing

When the Printing Method is Set to

When the Printing Method is Set to

When LCR Mode When Analyzer Mode
