5.6 Checking the Measurement Values
188
You can display a cursor in the measurement screen to check the measurement value of a measurement
point.
You can use the search function to easily find the maximum value, minimum value, and peak value.
Set the cursor to display in the measurement screen.
The two cursors "A" and "B" are available for use.
5.6 Checking the Measurement Values
5.6.1 Setting the Cursor
LCR
ANALYZER
Procedure
1
Measurement Value List Display
Analyzer Initial Screen
Press to change to [Graph Display]
before you set the cursor.
2
Analyzer Initial Screen
Press .
