1.3 Screen Configuration and Operation

13

1

Chapter 1 Overview

Select the measurement mode.

1.3.2 Measurement Mode Selection Screen

1

Press .

2

LCR Initial Screen

Select the measurement mode.Select

Mode Selection

LCR measurement (p. 37)

ANALYZER measurement (p. 131)

CONTINUOUS measurement (p. 265)

Initial screen is displayed.

Procedure
