6.3 Performing Continuous Measurement

267

Chapter 6 Continuous Measurement Function

6.3 Performing Continuous Measurement

CONTINUOUS

In the following circumstances, measurement will not continue after it:

• When the measurement result yields a contact check error or HIGH-Z reject error in low

Z high accuracy mode

• When the instrument is configured to halt measurement when the judgment result is

FAIL (HI/ LO/ OUT OF BINS) and the judgment function for the measured panel (com-

parator, BIN function) is enabled

Execute Continuous Measurement

Press .

Panels that were set to in the setting

screen are displayed in the list.

Stop Continuous Measurement

When you want to stop continuous

measurement: Press .
