Hioki IM3570 - Setting the Measurement Speed

4.2 Setting Basic Settings of Measurement Conditions
59
4
Chapter 4 LCR Function
The testing speed can be set. The slower the testing speed is, the more accurate are the results.
4.2.6 Setting the Measurement speed
Procedure
LCR Initial Screen
4
Press to close the setting screen.
1
LCR Basic Settings
To select the measurement speed.
3
The testing speed varies according to the number of
parameters being displayed, and according to their
type.
See "About Measurement Times and Measure-
ment Speed" (p. 399)
Performs high-speed measurement.
This is the normal measurement speed.
Measurement precision improves.
Measurement accuracy is better than
SLOW.
Measurement Speed Setting
Press .
2
LCR Basic Settings
