Hioki IM3570 - Horizontal Axis Scale Setting

5.5 Setting the Graph Display Method
177
5
Chapter 5 ANALYZER Function
Set the scale of the horizontal axis.
2
Horizontal Axis Scale Setting
Procedure
Analyzer Initial Screen
4
Press to close the setting screen.
3
Press .
2
Graph Settings
Graph Settings
Horizontal Axis Scale Setting
Select the draw type.
Sets the horizontal axis to linear (linear axis).
Sets the horizontal axis to log (logarithmic axis).
1
