7.3 Compensating Values to Match Reference Values (Load Compensation)

298

and Reference Value Settings

• If the compensation frequency, input mode or

reference values are incorrectly set, the load

compensation cannot be executed.

• If you make a mistake during input:

press to cancel the input and start again.

2. Use the numeric keypad to enter the reference value.

Reference Value Setting

1. Press .

3. Press a unit key to confirm the setting.

4. Press to confirm the setting.

5. Also set in the same way.

• If the compensation frequency, compensation range, and compensation level are not set,

the reference value setting cannot be set.

• When DC is selected for the compensation frequency setting, only reference value 1 can be set.
