Hioki IM3570 - 7.3 Compensating Values to Match

7.3 Compensating Values to Match Reference Values (Load Compensation)
296
Setting the DC Bias
If you make a mistake during input:
press to cancel the input and start again.
DC Bias Setting
2. Select ON/ OFF for the DC bias.
Sets the DC bias to OFF.
Sets the DC bias to ON.
3. Use or to enter the DC bias value.
Settable range: 0.00 to 2.50 V
4. Press to close the setting screen.
DC Bias Setting
1. Press .
• If the compensation frequency, compensation range, and compensation level are not set, the
DC bias setting cannot be set.
• When DC is selected for the compensation frequency setting, the DC bias setting cannot be
set.
