Appendix 12 Initial Settings Table
A17
The following table shows the initial settings of the instrument.
Appendix 12 Initial Settings Table
Yes: Available/ : The same as the left/ No: Unavailable
*1: When TYPE=ALL is set, the items indicated by Yes (ADJ) are also saved.
Setting Items Initial setting
Unit
Reset
Operatio
n Full
reset
:PRESet *RST
Return to
initial
settings
when
power is
turned on
Panel Save/
Load*
1
File
Save/
load
LCR
mode
ANALY
ZER
mode
Measurement mode LCR No Yes Yes Yes
Measurement parameter Z/OFF/
/OFF No Yes Yes Yes
Magnification display OFF No No No Yes
LCR basic
settings
Measurement frequency 1 kHz No Yes Yes Yes
Measurement
signal level
Mode V No Yes Yes Yes
V 1.000 V No Yes Yes Yes
CV 1.000 V No Yes Yes Yes
CC 10.00 mA No Yes Yes Yes
Measurement
range
Mode AUTO No Yes Yes Yes
Range 100 No Yes Yes Yes
LOW Z OFF No Yes Yes Yes
Trigger mode
INT
(Internal Trigger)
No Yes Yes Yes
DC bias
ON/OFF OFF No Yes Yes Yes
Bias value 0.00 V No Yes Yes Yes
Measurement speed MED No Yes Yes Yes
Limit
ON/OFF OFF No Yes Yes Yes
Current limit value 100.00 mA No Yes Yes Yes
Voltage limit value 5.000 V No Yes Yes Yes
Number of times for average 1 No Yes Yes Yes
Trigger delay 0.0000 s No Yes Yes Yes
LCR DC
resistance
measurement
Measurement
signal level
Mode V No Yes No Yes
V 1.00 V No Yes No Yes
CV 1.00 V No Yes No Yes
CC 10.00 mA No Yes No Yes
Measurement
range
Mode AUTO No Yes No Yes
Range 100 No Yes No Yes
LOW Z OFF No Yes No Yes
DC adjustment ON No Yes No Yes
Measurement speed MED No Yes No Yes
Limit
ON/O
FF
OF
F No Yes No Yes
Current limit value
100.00 mA No Yes No Yes
Voltage limit value
2.50 V No Yes No Yes
Number of times for average 1 No Yes No Yes
DC delay 0.0003 s No Yes No Yes
