Appendix 12 Initial Settings Table
A18
Application
settings
LCR judgment
mode
OFF/COMP/BIN OFF No Yes Yes Yes
Trigger synchro-
nous output
ON/OFF OFF No Yes Yes Yes
Trigger time 0.0010 s No Yes Yes Yes
Memory
OFF/IN/ON OFF No Yes Yes Yes
Number of memory
items
1000 No Yes Yes Yes
HIGH-Z Reject
ON/OFF OFF No Yes Yes Yes
Judgment reference
value
1000% No Yes Yes Yes
Detection level
monitoring
ON/OFF OFF No Yes Yes Yes
Detection level 10.00% No Yes Yes Yes
Detection sensitivity for measurement
errors
1 No No No Yes
Judgment result
Delay between
judgment results
and EOM
0.0000 s No No No Yes
Reset ON No No No Yes
IO trigger
ENABLE ON No No No Yes
Edge DOWN No No No Yes
IO-EOM
Mode HOLD

No No No Yes
EOM
output time 0.0050 s

No No No Yes
Key-lock
ON/OFF OFF No No No Yes
Passcode 3570 No No No Yes
Display digits 6/6/6/6 No Yes Yes Yes
Backlight ON No No No Yes
Beep sound
Judgment result NG No Yes Yes Yes
Key ON No No No Yes
LCR
Comparator
Mode ABS/ABS No Yes No Yes
Absolute value
mode
Upper limit value OFF/OFF No Yes No Yes
Lower limit value OFF/OFF No Yes No Yes
Percent mode
Reference value
1.000000k/
10.00000
No Yes No Yes
Upper limit value OFF/OFF No Yes No Yes
Lower limit value OFF/OFF No Yes No Yes
BIN
Mode ABS/ABS No Yes No Yes
Absolute value
mode
Upper limit value OFF/OFF No Yes No Yes
Lower limit value OFF/OFF No Yes No Yes
Percent mode
Reference value
1.000000k/
10.00000
No Yes No Yes
Upper limit value OFF/OFF No Yes No Yes
Lower limit value
OFF/OFF No Yes No Yes
Yes: Available/
: The same as the left/ No: Unavailable
*1: When TYPE=ALL is set, the items indicated by Yes (ADJ) are also saved.
Setting Items Initial setting
Unit
Reset
Operatio
n Full
reset
:PRESet *RST
Return to
initial
settings
when
power is
turned on
Panel Save/
Load*
1
File
Save/
load
LCR
mode
ANALY
ZER
mode
