Appendix
Appendix 12 Initial Settings Table
A19
ANALYZER
Basic settings
Sweep parameter Z-
No No Yes Yes
Main sweep parameter FREQ No No Yes Yes
Trigger REPEAT No No Yes Yes
Display timing REAL No No Yes Yes
Trigger delay 0.0000 s No No Yes Yes
Segment sweep OFF No No Yes Yes
Normal sweep
Sweep method START-STOP No No Yes Yes
Sweep start value 1 kHz No No Yes Yes
Sweep end value 1 MHz No No Yes Yes
Number of points 201 No No Yes Yes
Setting method of
measurement
points
LOG No No Yes Yes
Sweep signal
1.000 V
(V mode)
No No Yes Yes
Measurement range AUTO No No Yes Yes
Measurement speed MED No No Yes Yes
Number of times for average 1 No No Yes Yes
Point delay 0.0000 s No No Yes Yes
DC bias
ON/OFF OFF No No Yes Yes
Bias value 0 V No No Yes Yes
Analyzer graph
settings
Horizontal
Overwrite OFF No No Yes Yes
Scale LOG No No Yes Yes
Span SINGLE No No Yes Yes
Vertical
Color 1/2 No No Yes Yes
Scale LINEAR No No Yes Yes
Scale mode AUTO No No Yes Yes
Grid display PARA1 No No Yes Yes
ANALYZER
Comparator
settings
Mode OFF No No Yes Yes
Parameter PARA1 No No Yes Yes
Area display PARA1 No No Yes Yes
Peak No. to judge
Local minimum 1 No No Yes Yes
Local maximum 1
No No Yes Yes
Fi
lter for peak
search
OFF/ON ON No No Yes Yes
Reference value settings
MEAS VALUE
REFERENCE
No No Yes Yes
Reference value 1.000000k No No Yes Yes
Area Judgment
Upper limit value OFF/OFF No No Yes Yes
Lower limit value OFF/OFF No No Yes Yes
Peak Judgment
Left limit value OFF/OFF No No Yes Yes
Right limit value OFF/OFF No No Yes Yes
Upper limit value OFF/OFF No No Yes Yes
Lower limit value OFF/OFF No No Yes Yes
Yes: Available/
: The same as the left/ No: Unavailable
*1: When TYPE=ALL is set, the items indicated by Yes (ADJ) are also saved.
Setting Items Initial setting
Unit
Reset
Operatio
n Full
reset
:PRESet *RST
Return to
initial
settings
when
power is
turned on
Panel Save/
Load*
1
File
Save/
load
LCR
mode
ANALY
ZER
mode
To Next Page
