Appendix 12 Initial Settings Table
A20
Analyzer
cursor and
search settings
Cursor display ON/OFF OFF No No Yes Yes
Cursor to move A No No Yes Yes
Cursor A
Search mode L-MAX No No Yes Yes
Parameter PARA1 No No Yes Yes
Target value 0.000000 No No Yes Yes
Cursor B
Search mode L-MAX No No Yes Yes
Parameter PARA1 No No Yes Yes
Target value 0.000000 No No Yes Yes
Filter ON/OFF ON No No Yes Yes
Auto search ON/OFF OFF No No Yes Yes
Equivalent
circuit analysis
function
(optional
IM9000)
Model selection method OFF

No No Yes Yes
Equivalent circuit model A

No No Yes Yes
Analysis execution method MANUAL

No No Yes Yes
Analysis start frequency 4 Hz

No No Yes Yes
Analysis stop frequency 5 MHz

No No Yes Yes
Segment to analyze ALL

No No Yes Yes
Electromechani-
cal coupling coeffi-
cient (K)
Oscillation mode Kr

No No Yes Yes
Frequency type fs-fp

No No Yes Yes
Coefficient a 0.395000

No No Yes Yes
Coefficient b 0.574000

No No Yes Yes
Display position LEFT

No No Yes Yes
Estimated value
R1 0.0

No No Yes Yes
L1 0.0

No No Yes Yes
C1 0.0

No No Yes Yes
C0 0.0

No No Yes Yes
Equivalent
circuit analysis
comparator
function
(optional
IM9000)
Comparator ON/OFF OFF

No No Yes Yes
R1
Upper limit value
OFF

No No Yes Yes
Lower limit value
OFF

No No Yes Yes
L1
Upper limit value
OFF

No No Yes Yes
Lower limit value
OFF

No No Yes Yes
C1
Upper limit value
OFF

No No Yes Yes
Lower limit value
OFF

No No Yes Yes
C0
Upper limit value
OFF

No No Yes Yes
Lower limit value
OFF

No No Yes Yes
Qm
Upper limit value
OFF

No No Yes Yes
Lower limit value
OFF

No No Yes Yes
Continuous
measurement
Measurement target ON/OFF ON No No No No
Display timing REAL No No No Yes
Trigger SEQUENTIAL No No No Yes
Measurement halt at FAIL judgment
result
OFF No No No Yes
Open circuit
compensation
Compensation mode OFF 
No
Change
OFF No
Yes
(ADJ)
Yes
(ADJ)
Yes
Parameter type G-B 
No
Change
G-B No
Yes
(ADJ)
Yes
(ADJ)
Yes
Correction value
G Correction value 0.0000nS 
No
Change
0.0000
nS
No
Yes
(ADJ)
Yes
(ADJ)
Yes
B Correction value 0.0000nS 
No
Change
0.0000
nS
No
Yes
(ADJ)
Yes
(ADJ)
Yes
Open compensation conditions All valid 
No
Change
All
valid
No
Yes
(ADJ)
Yes
(ADJ)
Yes
Yes: Available/
: The same as the left/ No: Unavailable
*1: When TYPE=ALL is set, the items indicated by Yes (ADJ) are also saved.
Setting Items Initial setting
Unit
Reset
Operatio
n Full
reset
:PRESet *RST
Return to
initial
settings
when
power is
turned on
Panel Save/
Load*
1
File
Save/
load
LCR
mode
ANALY
ZER
mode
