Hioki IM3570 - Setting the Measurement Range; Setting AUTO Ranging

4.3 Setting DC Resistance Measurement
69
4
Chapter 4 LCR Function
There are the following two methods for setting the measurement range.
4.3.2 Setting the Measurement Range
1
Setting AUTO Ranging
AUTO
The most suitable test range is set automatically.
(This allows the most suitable measurement range to be set when, for example,
measuring a test sample whose nature is unknown.)
HOLD
The test range is fixed, and may only be altered manually.
(When the range is fixed, high-speed measurement is possible.)
Procedure
LCR Initial Screen
Press .
2
1
Rdc Basic Settings
Rdc Basic Settings
