5.6 Checking the Measurement Values
190
2
Cursor Move Setting
3
Search Function Setting
Cursor Move Setting
Select the cursor to move using the cursor
move keys on the measurement screen.
See "5.6.2 Moving the Cursor" (p. 193)
Moves cursor A.
Moves cursor B.
This can only be set when is selected for the display cursor setting.
Search Function Setting
Set the search function.
See "Performing Measurement Value Search" (p. 194)
Moves the cursor to the maximum value of the
measurement results.
Moves the cursor to the minimum value of the
measurement results.
Moves the cursor to the measurement value
set in the option settings.
Moves the cursor to the local maximum value
of the measurement results.
The filter can be set in the option settings.
Moves the cursor to the local minimum value of
the measurement results.
The filter can be set in the option settings.
The search function does not work during a sweep.
When you use the search function, the setting
needs to be set to or .
See "5.2.3 Setting the Trigger" (p. 137)
