4.4 Judging Measurement Results

101

4

Chapter 4 LCR Function

3

Setting Upper and Lower Limit Values as (%) Values Relative to the Offset

from the Reference Value (Deviation Percentage Mode)

Procedure

1

Press .

2

Press .

3

Press to select percentage mode.

BIN Settings

BIN Mode Setting

The button display differs depending on the

measurement parameter.
