Hioki IM3570 - Setting the DC Bias

5.3 Normal Sweep
167
5
Chapter 5 ANALYZER Function
For the DC bias setting, set the DC bias value for when sweep measurement is performed.
If the DC bias is set, a DC signal can be superimposed on the measurement signal.
5.3.7 Setting the DC Bias
Procedure
Press .
Analyzer Initial Screen Analyzer Basic Settings
1
Analyzer Basic Settings
2
3
DC Bias Setting
Select ON/ OFF for the DC bias.
Sets the DC bias to OFF.
Sets the DC bias to ON.
Press this button when using an external
DC bias unit.
The DC bias will be set to ON, and the bias
value will be set to 0.00 V.
