13.1 General Specifications
388
Measurement signal level (1) Open circuit terminal voltage (V) mode and constant voltage (CV) mode
• Level range
Normal mode: 5 mV to 5 V, maximum 50 mA (up to 1.0000 MHz)
10 mV to 1 V, maximum 10 mA (from 1.0001 MHz)
Low Z high accuracy mode: 5 mV to 1 V, maximum 100 mA (up to 100.00 kHz)
• Setting resolution 1 mV steps
• Setting accuracy
±10% of setting ±10 mV (up to 1.0000 MHz)
±20% of setting ±10 mV (from 1.0001 MHz)
(2) Constant current (CC) mode
• Level range
Normal mode: 10
A to 50 mA, maximum 5 V (up to 11.0000 MHz)
10
A to 10 mA, maximum 1 V (from 1.0001 MHz)
Low Z high accuracy mode: 10 A to 100 mA, maximum 1 V (100 m and 1  ranges
of 100 kHz or less)
10
A to 10 mA (other than the above)
• Setting resolution 10
A steps
• Setting accuracy
±10% of setting ±10 A (up to 1.0000 MHz)
±20% of setting ±10 A (from 1.0001 MHz)
Measurement range The measurement range is determined according to impedance Z.
The values of the other measurement items can be calculated.
Ranges: 100 m
, 1 , 10 , 300 , 1 k, 3 k, 10 k, 30 k, 100 k, 1 M,
10 M, 100 M (12 ranges)
• The guaranteed accuracy range differs depending on the measurement conditions.
(p. 398)
• Out of guaranteed accuracy is displayed when out of the ranging range
OVERFLOW or UNDERFLOW is displayed when out of the A/D input range
1.Basic Specifications
Measurement range Guaranteed Accuracy Range AUTO Ranging Range
100 M 8 M to 200 M 8 M to 999.999 M
10 M 800 k to 100 M 800 k to 10 M
1 M 80 k to 10 M 80 k to 1 M
100 k 24 k to 1 M 24 k to 100 k
30 k 8 k to 300 k 8 k to 30 k
10 k 2.4 k to 100 k 2.4 k to 10 k
3 k 800  to 30 k 800  to 3 k
1 k 240  to 10 k 240  to 1 k
300  8  to 300  8  to 300 
10  800 m to 10  800 m to 10 
1  80 m to 1  80 m to 1 
100 m 1 m to 100 m 0  to 100 m
