1.3 Screen Configuration and Operation
15
1
Chapter 1 Overview
Initial screen is displayed.
DC resistance measurement setting
Measurement signal level setting (p. 66)
Measurement range setting (p. 69)
Average setting (p. 80)
DC delay setting (p. 82)
Measurement speed setting (p. 77)
DC adjustment setting (p. 75)
Voltage and current limit settings (p. 78)
Measurement result judgment setting
(p. 84)
Trigger synchronous output function
(p. 104)
Key-lock setting (p. 121)
Number of display digits setting for each
parameter (p. 124)
LCD setting (p. 127)
Initial screen is displayed.
Application settings
Panel loading and saving (p. 315)
System reset (p. 129)
Beep sound setting (p. 128)
HIGH-Z reject function setting (p. 108)
IO setting (p. 115), (p. 117)
Detection level monitoring function
setting (p. 110)
Save settings of measurement results
(p. 106)
Set detection sensitivity for measurement
errors (p. 113)
