9.2 Loading Measurement Conditions (Panel Load Function)
323
8
9
Chapter 9 Saving and Loading Panel Information
When you want to return to the panel number
selection screen:
Press .
You can check the information of a saved panel:
Panel Information Confirmation
When is selected
Use or to switch to the information of the
previous or next panel.
4
Returns to the previous screen.
Reads the measurement conditions of the
selected panel number.
(The [Initial Screen] is redisplayed automati-
cally.)
5
When reading of the measurement conditions is finished, the [Initial Screen] is redisplayed auto-
matically.
The read confirmation screen appears.
Panel Load Confirmation
Display of Loaded Panel Number
The loaded panel number is displayed
in the initial screen.
