Select whether to reset the comparator and
BIN judgment results simultaneously with the
measurement start signal.
Stores the last judgment results until the next
judgment results are output.
Resets the judgments results at the time of the
measurement start signal.
5
I/O Judgment Setting
6
Press to close the setting screen.
4
I/O Judgment Setting
Use or to set the delay time for the
period from the output of the comparator and
BIN judgment results until the output of EOM
(LOW).
• Settable range: 0.0000 s to 0.9999 s
• If you make a mistake during input:
press to cancel the input and start
again.
To Next Page
