4.5 Setting Application Settings
118
4
I/O Trigger Setting
5
Press to close the setting screen.
Sets the falling edge as the valid edge of trigger
input.
Sets the rising edge as the valid edge of trigger
input.
Disables trigger input from the EXT I/O during
measurement (during EOM
(HI) output after
trigger is received).
Enables trigger input from the EXT I/O during
measurement (during EOM
(HI) output after
trigger is received).
Select the I/O trigger function setting.
