4
Press to close the setting screen.
3
Measurement Parameter Setting
Select the first parameter.
Select the second parameter.
LCR mode ANALYZER mode
PARA1 PARA1
PARA2 Unused
PARA3 PARA2
PARA4 Unused
• In analyzer mode, two types of parameter mea-
surement can be performed: PARA1 and PARA2.
• The parameter settings of LCR mode and parame-
ter settings of analyzer mode are synchronized as
shown below.
To Next Page
